AIRCAT 6255 Composite Angle Air Die Grinder, 1/4" Collet, 20000 RPM, Rear Exhaust

AIRCAT 6255 Composite Angle Air Die Grinder, 1/4" Collet, 20000 RPM, Rear Exhaust

• AIRCAT 6255 is a composite angle die grinder designed for high speed blending, smoothing, porting, and deburring in confined areas. It delivers 20,000 RPM free speed with a 0.4 HP motor, a 1/4 inch collet, spiral bevel gears, and rear exhaust for controlled grinding and finishing work.
• Features:
  • 20,000 RPM free speed supports fast material removal for blending, smoothing, porting, and deburring.
  • 0.4 HP motor provides power for common angle die grinder tasks in automotive and general service work.
  • 1/4 inch collet fits 1/4 inch shank accessories used with die grinders.
  • Spiral bevel gears support right angle drive performance and durability in repeated use.
  • Rear exhaust directs air away from the work area to support better control during operation.
• Specifications:
  • Manufacturer: AIRCAT
  • Part Number: 6255
  • Product Name: AIRCAT .4 HP Composite Angle Die Grinder
  • Product Type / Function: Pneumatic angle die grinder
  • Free Speed: 20,000 RPM
  • Motor Power: 0.4 HP
  • Collet Size: 1/4 inch
  • Gears: Spiral bevel
  • Exhaust: Rear
  • Weight: 1.10 lb
  • Length: 7 inches
  • Air Consumption: 4.2 cfm
  • Recommended Hose Size: 3/8 inch
  • Air Inlet: 1/4 inch NPT
  • System Compatibility or Application: Designed for high speed blending, smoothing, porting, and deburring in confined areas
  • Quantity: 1 angle die grinder
• The AIRCAT Composite Angle Die Grinder can also be referred to as a right angle die grinder, a pneumatic angle die grinder, a 1/4 inch collet die grinder, a 20,000 RPM angle die grinder, and a composite air die grinder.

AIRCAT is a manufacturer of high-performance pneumatic power tools, primarily known for its impact wrenches, ratchets, and grinders. Founded in 1998 and now a part of the Continental Tool Group, the brand specializes in tools that offer high torque with significantly reduced noise levels—often marketed under the slogan "More Power, Half the Noise".

Q: What accessory shank size fits this tool?
A: It uses a 1/4 inch collet, so it is designed for 1/4 inch shank accessories.

Q: What is the free speed rating?
A: The listed free speed is 20,000 RPM.

Q: What air connections should I plan for?
A: It uses a 1/4 inch NPT air inlet and lists a 3/8 inch recommended hose size to support airflow.

Q: What type of jobs is this angle die grinder designed for?
A: It is designed for blending, smoothing, porting, and deburring, including work in confined areas where an angle head helps access.
