Arconic M39011 Marson HP-5 Hand Riveter, 3/32" to 3/16" Rivets, 4 Nosepieces, Service Wrench

Arconic M39011 Marson HP-5 Hand Riveter, 3/32" to 3/16" Rivets, 4 Nosepieces, Service Wrench

• Manual blind rivet installation tool for automotive, fabrication, maintenance, and assembly applications. The HP-5 retains the rivet in the working nosepiece while the tool is positioned for installation.
• Features:
  • Drop-forged steel handle is heat-treated for demanding hand riveting applications.
  • Die-cast aluminum alloy body incorporates a steel insert and anti-wear fulcrum pin.
  • Ergonomic handles increase leverage during rivet installation.
  • Four interchangeable nosepieces are changed using the included service wrench.
• Includes:
  • HP-5 Hand Riveter
  • 3/32" Nosepiece
  • 1/8" Nosepiece
  • 5/32" Nosepiece
  • 3/16" Nosepiece
  • Service Wrench
• Specifications:
  • Manufacturer: Arconic
  • Part Number: M39011
  • Brand: Marson
  • Model: HP-5
  • Product Type: Hand Riveter
  • Rivet Sizes: 3/32", 1/8", 5/32", and 3/16"
  • Rivet Capacity: Up to 5/32" in all alloys and 3/16" in steel
  • Body Material: Die-cast aluminum alloy with steel insert
  • Handle Material: Drop-forged steel
• The Marson HP-5 Hand Riveter can also be referred to as manual blind riveter, hand rivet gun, blind rivet installation tool, Klik-Fast riveter, and manual pop rivet tool.

Arconic has produced engineered fastening systems and installation tooling for transportation, automotive, industrial, and manufacturing applications. Its Marson product family includes blind rivets, rivet nuts, and manual and powered installation tools.

Q: What rivet sizes can the Marson M39011 HP-5 install?
A: It uses 3/32", 1/8", 5/32", and 3/16" nosepieces.

Q: What rivet materials can the HP-5 handle?
A: It sets 3/32", 1/8", and 5/32" rivets in all alloys and up to 3/16" rivets in steel.

Q: Are the nosepieces included with the M39011?
A: Yes. Four standard nosepieces and a service wrench are included.

Q: Does the HP-5 retain the rivet while the tool is positioned?
A: Yes. Its design retains the rivet in the nosepiece while the tool is held in different working positions.
