Tiger Tool 90150 King Pin Press, Heavy Duty King Pin Press for Class 3-8 Trucks, Semi Trucks and Heavy Equipment

Tiger Tool 90150 Heavy-Duty King Pin Press, 46000 lb Force, Class 3-8 Trucks and Heavy Equipment

• The Tiger Tool 90150 Heavy-Duty King Pin Press is designed for removing straight and tapered king pins from 7/8" to 2-5/32" on Class 3-8 trucks, semi trucks, pickups, buses, and heavy equipment. The press generates up to 46000 lb of force, weighs approximately 30 lb., and includes three forcing screw options so one technician can service a broad range of king pin applications.
• Features:
  • Generates up to 46000 lb of pressing force.
  • Designed for one-person operation.
  • Weighs approximately 30 lb., substantially reducing handling weight compared with heavier press designs.
  • High-grade steel diamond-shaped end plates reduce overall tool mass.
  • Anti-torque arms help prevent twisting of the main body under high force.
  • Engineered for use with impact tools up to 1".
  • Includes three forcing screw options for applications ranging from 3/4-ton pickups through Class 8 trucks.
  • Shortened 1-1/4" forcing screw improves access in confined wheel wells, including bus applications.
  • Designed for straight and tapered king pins from 7/8" to 2-5/32".
  • Includes three tie rod end removers for additional steering and suspension service capability.
• Includes:
  • (1) Tiger Tool 90150 Heavy-Duty King Pin Press
  • (3) Forcing Screw Options
  • (1) Shortened 1-1/4" Forcing Screw
  • (1) Tiger Tool 10301 Tie Rod End Remover
  • (1) Tiger Tool 10302 Tie Rod End Remover
  • (1) Tiger Tool 10304 Tie Rod End Remover
• Compatible Applications:
  • Class 3-8 Trucks
  • Semi Trucks
  • 3/4-Ton Pickups
  • Heavy Equipment
  • Bus Applications
  • Straight King Pins
  • Tapered King Pins
  • Ram 3500 and 5500
  • Chevrolet 3500 and 5500
  • Ford F-350 and F-550
  • Isuzu NPR
  • Kenworth
  • Peterbilt
  • Freightliner
  • Mack
  • Volvo
• Compatible King Pin Sizes:
  • Minimum King Pin Diameter: 7/8"
  • Maximum King Pin Diameter: 2-5/32"
  • Optional 90153 Clearance Plate Adapter allows service of 2-1/2" king pins.
• Compatible Tools and Accessories:
  • Tiger Tool 90153 Clearance Plate Adapter for 2-1/2" king pins, Sold Separately
  • Optional Isuzu NPR and GMC/Chevrolet W-Series Adapter, Sold Separately
• Application Notes:
  • Not compatible with FL981 axles where the tie rod is cast to the spindle.
• Specifications:
  • Manufacturer: Tiger Tool
  • Part Number: 90150
  • MPN: 90150
  • UPC: 0068355290150
  • Product Line: TIG
  • Product Type: Heavy-Duty King Pin Press
  • Maximum Force: 46000 lb.
  • Tool Weight: Approximately 30 lb.
  • King Pin Range: 7/8" to 2-5/32"
  • Maximum Impact Tool Size: 1"
  • Forcing Screw Options: 3
  • Short Forcing Screw Size: 1-1/4"
  • Application: Class 3-8 Trucks, Semi Trucks, Pickups, Buses and Heavy Equipment
• This item is also often referred to as a king pin press, heavy-duty king pin remover, Class 8 king pin press, truck king pin tool, semi truck king pin press, heavy equipment king pin remover, and Tiger Tool 90150 press.

Tiger Tool manufactures heavy-duty automotive and commercial vehicle service tools for steering, suspension, driveline, wheel-end, and undercarriage repair applications used by truck, fleet, and heavy equipment technicians.

Q: What size king pins can the Tiger Tool 90150 remove?
A: It is designed for straight and tapered king pins from 7/8" to 2-5/32". An optional 90153 adapter is listed for 2-1/2" king pins.

Q: How much force does the Tiger Tool 90150 generate?
A: It can generate up to 46000 lb of force.

Q: What types of vehicles can the Tiger Tool 90150 service?
A: It is intended for applications ranging from 3/4-ton pickups through Class 8 trucks, including select Ram, Chevrolet, Ford, Isuzu, Kenworth, Peterbilt, Freightliner, Mack, Volvo, bus, and heavy equipment applications.

Q: Are there any applications where the Tiger Tool 90150 should not be used?
A: Yes. It is not compatible with FL981 axles where the tie rod is cast to the spindle.
