OTC SMT500 SMT 500 Low Pressure Leak Tester Smoke Machine, 0.01" Leak Detection

OTC SMT500 SMT 500 Low Pressure Leak Tester Smoke Machine, 0.01" Leak Detection

• OTC SMT500 is a compact, lightweight low pressure leak tester for automotive leak applications, mobile repairs, field vehicle testing, and fleet repairs. It has an on-board micro air compressor, variable flow control, pressure decay testing, and OEM-approved smoke agent for low pressure sealed systems.
• Features:
  • On-board micro air compressor eliminates the need for an external compressed shop air source.
  • Variable flow control and OEM-approved smoke agent are used to detect leaks as small as 0.01" in low pressure sealed systems.
  • Pressure decay testing confirms leaks are repaired accurately the first time.
  • Compact 11 lb design for mobile repairs, field vehicle testing, and fleet repairs.
• Includes:
  • SMT 500
  • Easy INTAKE Inflatable Bladder
  • Cap Plug Kit
  • Cordless LED Light
  • Schrader Valve Removal Tool
  • EVAP Service Port Adapter
  • OEM-Approved Smoke Agent
  • Durable Storage Case
• Specifications:
  • Manufacturer: OTC Tools & Equipment
  • Part Number: SMT500
  • UPC: 28851046008
  • Product Type: Low pressure leak tester smoke machine
  • Leak Detection: As small as 0.01" in low pressure sealed systems
  • Power Supply: 12 volts DC; 11.5-14 volts DC input
  • Power Consumption: 8 amps
  • Output Pressure: 0.47 PSI / 13.0 in. H2O / 0.032 BAR
  • Operating Modes: Vapor test cycle and air-only test cycle
  • Pressure Supply: On-board micro air compressor
  • Vapor Output Hose: 10 feet
  • Power Supply Cables: 10 feet
  • Housing Material: High-impact PC/ABS polycarbonate
  • Vapor Chamber Material: Billet aluminum
  • Product Dimensions: 8" x 10" x 12.5"
  • Product Weight: 11 lb
  • Quantity: 1 kit
• The SMT 500 Low Pressure Leak Tester Smoke Machine can also be referred to as low pressure leak tester, automotive smoke machine, EVAP smoke tester, portable leak tester, and 12 volt leak detector.

OTC Tools & Equipment is a Bosch Automotive Service Solutions brand supplying professional diagnostic equipment, specialty service tools, shop equipment, and heavy-duty service tools for automotive and commercial vehicle repair.

Q: What automotive systems can OTC SMT500 test?
A: It can test vacuum, EVAP, exhaust, oil, manifold, hose, cooling system, wind, and water leaks.

Q: Does the tester require shop air during use?
A: No. The on-board micro air compressor eliminates the need for an external compressed shop air source or inert gas tank during use.

Q: What are the power requirements?
A: The tester runs on 12 volts DC with an 11.5-14 volts DC input range and 8 amp power consumption.
