Brush Research Flex-Hone GBD41432 GBD Heavy Duty Flexible Cylinder Hone, 4-1/4" Bore, 320 Grit, Silicon Carbide, for Bore Finishing and Deburring

Brush Research Flex-Hone GBD41432 GBD Heavy Duty Flexible Cylinder Hone, 4-1/4" Bore, 320 Grit, Silicon Carbide, for Bore Finishing and Deburring

• Brush Research GBD41432 is a Flex-Hone GBD heavy duty flexible cylinder hone designed for surface finishing and deburring in bores from 4.001 inches to 4.25 inches. It uses 320 grit silicon carbide abrasive globules with a 6 inch abrasive part and 13.5 inches overall length to help create a consistent bore finish.
• Features:
  • 4.25 inches bore diameter with a 4.001 inches to 4.25 inches bore range helps match nominal 4-1/4 inch applications for proper tool fit.
  • 320 grit silicon carbide abrasive supports extra fine surface finishing and deburring on mild steel, stainless steel, cast iron, and other softer ferrous materials.
  • 6 inch abrasive part helps maintain stable contact through longer bores for repeatable finishing results.
  • Self-centering, self-aligning, and self-compensating for wear construction helps maintain uniform bore contact during operation.
  • Recommended 350 to 600 RPM operation with lubrication required supports controlled cutting action and helps reduce abrasive loading.
• Specifications:
  • Manufacturer: Brush Research
  • Part Number: GBD41432
  • Manufacturer Part Number: GBD41432
  • Product Type: Flex-Hone GBD heavy duty flexible cylinder hone
  • Bore Diameter: 4.25 inches (108 mm)
  • Minimum Bore Diameter: 4.001 inches
  • Maximum Bore Diameter: 4.25 inches
  • Overall Length: 13.5 inches
  • Abrasive Part Length: 6 inches
  • Abrasive Type: Silicon carbide
  • Grit: 320
  • Stem Diameter: 0.31 inches
  • Tip Marking: White
  • Stem Marking: Silver or no color
  • Recommended RPM: 350 to 600
  • Feed Rate: 10 to 2500 ipm
  • Lubrication: Required
  • Power Requirements: 1/3 hp to 1/2 hp
  • Ra Range: 18 to 30 microinch (0.5 to 0.7 micrometer)
  • Applicable Materials: Mild steel, stainless steel, cast iron, and other softer ferrous materials
  • Quantity: 1
  • System Compatibility or Application: Designed for surface finishing and deburring in internal bores sized 4.001 inches to 4.25 inches.
• The Flex-Hone GBD heavy duty flexible cylinder hone can also be referred to as flexible cylinder hone, silicon carbide ball hone, 4-1/4 inch brake cylinder hone, cylinder bore finishing tool, and GBD heavy duty flex hone.

Brush Research is a privately held company in Los Angeles, California, specializing in flexible honing tools and industrial brushes for surface finishing and deburring. The company has produced brushing technology solutions since 1958.

Q: What bore size range does this hone fit?
A: It is designed for bore sizes from 4.001 inches to 4.25 inches, with a nominal bore diameter of 4.25 inches (108 mm).

Q: What abrasive and grit does GBD41432 use?
A: It uses silicon carbide abrasive globules in 320 grit.

Q: What operating speed is recommended?
A: The recommended operating speed range is 350 to 600 RPM.

Q: Do I need to use lubricant with this hone?
A: Yes. Lubrication is required during use.
