Graco 224450 Repair Kit for 500 Series Hose Reels, Swivel Seal Service Kit

Graco 224450 Repair Kit for 500 Series Hose Reels, Swivel Seal Service Kit

• Graco 224450 is a repair kit for compatible 500 Series hose reels. This kit provides the swivel sealing components identified in Graco's official parts list for supported low and medium pressure 500 Series reel assemblies.
• Features:
  • Official Graco repair kit helps service compatible 500 Series hose reel assemblies using listed replacement sealing parts.
  • Includes backup rings and O-rings used in the reel swivel area, supporting maintenance of the original assembly.
  • Designed for compatible Graco 500 Series hose reels identified in the official service manual parts list.
  • Two distinct replacement component types are included, making this a true repair kit rather than a single replacement part.
• Includes:
  • Ring, Back-Up (108235), quantity 2
  • O-Ring, Buna-N (166702), quantity 2
• Specifications:
  • Manufacturer: Graco
  • Part Number: 224450
  • MPN: 224450
  • UPC: 633955201255
  • Product Type: Repair kit
  • Kit Contents: Backup rings and O-rings
  • Component Quantity: 4 total pieces
  • Seal Material Reference: Buna-N O-rings
  • System Compatibility or Application: Designed for compatible Graco 500 Series hose reels, including models listed in the official 500 Series hose reel service manual low and medium pressure parts section
• The Repair Kit can also be referred to as 500 Series reel repair kit, hose reel swivel seal kit, Graco reel seal kit, backup ring and O-ring kit, and hose reel service kit.

Graco manufactures fluid handling equipment, hose reels, pumps, spray systems, and replacement parts for industrial and maintenance applications. The brand is widely used in lubrication, material transfer, finishing, and service environments.

Q: What does Graco 224450 include?
A: The official parts list identifies two backup rings, part 108235, and two Buna-N O-rings, part 166702.

Q: Is this a replacement part for a specific product line?
A: Yes. This kit is designed for compatible Graco 500 Series hose reels identified in the official service manual parts listing.

Q: Why is there an Includes section for this SKU?
A: This SKU contains two distinct component types, backup rings and O-rings, so the Includes section is required.

Q: Is this a complete hose reel rebuild kit?
A: No. The official parts list identifies this as a repair kit containing specific sealing components, not a complete reel rebuild assembly.
