Mityvac MV6835 Vacuum Brake Bleed Kit, 1.9 Quart Reservoir, 40 Ounce Auto-Refill Kit

Mityvac MV6835 Vacuum Brake Bleed Kit, 1.9 Quart Reservoir, 40 Ounce Auto-Refill Kit

• Mityvac MV6835 uses compressed air operation with an integrated 1.9 quart fluid collection reservoir. It includes an automatic master cylinder refill kit with 40 ounce reservoir and adapters, plus a variable control thumb throttle and swivel air inlet with quick disconnect.
• Features:
  • Compressed air operation.
  • Integrated 1.9 quart (1.8 liter) capacity fluid collection reservoir.
  • Variable control thumb throttle.
  • Swivel air inlet with quick disconnect.
  • Automatically maintains fluid level in master cylinder.
• Includes:
  • Brake bleeder
  • 6 foot bleed hose assembly
  • 4 foot fluid evacuation hose
  • Molded base with screws for bench mounting
  • Hanging hook
  • 3 universal bleed screw adapters
  • MVA6832 clamp-on master cylinder auto-refill kit
  • User manual in English, French, Spanish, and German
• Specifications:
  • Manufacturer: Mityvac
  • Part Number: MV6835
  • UPC: 646541001771
  • Product Type: Vacuum brake bleed kit
  • Evac Reservoir Capacity: 1.9 quarts (1.8 liters)
  • Refill Reservoir Capacity: 40 ounces (1.2 liters)
  • Working Pressure: 60 to 150 psi (4.1 to 10.3 bar)
  • Vacuum at 90 psi: 26" Hg (88 kPa)
  • Air Consumption at 90 psi: 4.3 cfm (2.0 liters per second)
  • Flow Rate at 60 psi: 50 ounces per minute (1460 milliliters per minute)
  • Flow Rate at 90 psi: 70 ounces per minute (2100 milliliters per minute)
  • Flow Rate at 150 psi: 70 ounces per minute (2100 milliliters per minute)
  • Inlet Thread Size: 1/4" NPT
  • Applications: Brake bleeding, hydraulic clutch bleeding, fluid evacuation
  • CE Certified: Yes
• The Vacuum Brake Bleed Kit can also be referred to as pneumatic brake bleeder kit, vacuum brake bleeder, hydraulic clutch bleed kit, master cylinder auto-refill brake bleeder, and fluid evacuation brake tool.

Mityvac is an American brand of automotive diagnostic, service, and repair tools founded in 1971 and part of SKF Group. Its products cover brake bleeding, clutch bleeding, fluid handling, and automotive diagnostics.

Q: What service applications is Mityvac MV6835 used for?
A: It is used for brake bleeding, hydraulic clutch bleeding, and fluid evacuation.

Q: What working pressure range does the kit use?
A: The specified working pressure range is 60 to 150 psi.

Q: What does the auto-refill kit do during brake bleeding?
A: The clamp-on master cylinder auto-refill kit automatically maintains the fluid level in the master cylinder.
