Milton 1180-2 Automatic Condensate Drain, 1/2 Inch FNPT, Aluminum Body, 175 PSI Max

Milton 1180-2 Automatic Condensate Drain, 1/2 Inch FNPT, Aluminum Body, 175 PSI Max

• Milton 1180-2 is a float type automatic condensate drain designed to remove water from compressed air lines to help provide cleaner, drier air. It installs on the down leg of an air line run and includes a protective stainless steel screen with an umbrella baffle plus a top threaded port.
• Features:
  • 1/2 Inch FNPT drain connection supports installation on compatible air line drop legs to remove condensate before the filter.
  • Float type automatic operation helps drain accumulated water from the air line without manual bleeding.
  • Protective stainless steel screen with umbrella baffle helps reduce debris entry and supports consistent draining.
  • Top threaded port supports common drop leg installation layouts in shop compressed air systems.
  • Designed for compressed air condensate removal using the 1180-2 drain, not a replacement part for a specific vehicle or machine.
• Specifications:
  • Manufacturer: Milton
  • Part Number: 1180-2
  • MPN: 1180-2
  • UPC: 030937308504
  • Alternate Part Numbers / Cross References: S-1180-2; MI1180-2
  • Category: Pneumatics
  • Subcategory: FRL Accessories
  • Product Type / Function: Automatic condensate drain
  • Thread Size: 1/2 Inch FNPT
  • Material: Aluminum
  • Maximum Pressure: 175 PSI
  • Drain Type: Float type automatic
  • Screen Material: Stainless steel
  • System Compatibility Or Application: Designed to be installed on the down leg of a compressed air line run to remove water before the filter and help provide clean, dry air
  • Quantity: 1 drain
• The Milton 1180-2 Automatic Condensate Drain can also be referred to as an automatic air line drain, a compressed air condensate drain, a float type condensate drain, a 1/2 Inch FNPT condensate drain, and an FRL condensate drain accessory.

Milton manufactures pneumatic accessories and compressed air connection products used in automotive service, industrial maintenance, and shop air systems. The brand product line includes air fittings, couplers, plugs, gauges, and air management components for routine technician use.

Q: Where should this drain be installed in a shop air system?
A: It is typically installed on the down leg of the air line run so water is removed before reaching the filter.

Q: What thread size does it use?
A: It uses 1/2 Inch FNPT threads for connection to compatible air line fittings.

Q: What type of drain mechanism does it use?
A: It is a float type automatic condensate drain that opens to release water as condensate accumulates.

Q: What is the maximum working pressure?
A: The maximum pressure rating is 175 PSI.
