UView CSVP4S Vacuum Pump, 4 CFM, Single Stage, Dual Voltage 110 to 120 V / 220 V
- UView CSVP4S is a compact single stage vacuum pump rated at 4 CFM with a dual voltage 1/3 HP motor. It is designed for quick, deep evacuation of A/C and refrigeration systems, featuring multiple intake fittings and a thermally protected motor for dependable shop use.
- Features:
- 4 CFM single stage performance helps achieve target vacuum levels efficiently during system evacuation
- Dual voltage motor operates on 110 to 120 V or 220 V at 50 or 60 Hz for shop flexibility
- Ultimate vacuum to 50 micron supports moisture and noncondensable removal prior to charging
- Multiple intake fittings 1/4 in SAE, 3/8 in SAE, and 1/2 in ACME for direct hookup to common service hoses
- Thermally protected motor and solid base improve reliability for routine automotive A/C service
- Specifications:
- Manufacturer: UView
- Part Number: CSVP4S
- Free Air Displacement: 4 CFM at 60 Hz; 96 L/min at 50 Hz
- Stage: Single stage
- Motor: 1/3 HP, 2880 to 3440 RPM, dual voltage 110 to 120 V or 220 V, 50/60 Hz
- Ultimate Vacuum: 50 micron
- Intake Fittings: 1/4 in SAE, 3/8 in SAE, 1/2 in ACME
- Oil Capacity: 16 oz
- Housing / Base: Heavy gauge aluminum chassis with rubber base
- Overall Dimensions: 12.2 in x 5 in x 9.6 in
- System Compatibility / Application: For evacuating automotive and light refrigeration A/C systems prior to charging
- Alternate Part Numbers / Cross References: CPS VP4S; distributor references list CSVP4S as the order code
- The Vacuum Pump can also be referred to as 4 CFM vacuum pump, single stage vacuum pump, dual voltage vacuum pump, automotive AC vacuum pump, and CPS VP4S equivalent.
UView supplies professional A/C service equipment and accessories for automotive technicians. The brand is associated with CPS Products, a manufacturer of HVAC and automotive service tools distributed through professional channels.
Q: Is CSVP4S dual voltage from the factory?
A: Yes. It is specified for 110 to 120 V or 220 V operation at 50 or 60 Hz. Confirm your local voltage and follow the wiring and plug guidance provided by the seller.
Q: What hose connections are supported?
A: The pump provides 1/4 in SAE, 3/8 in SAE, and 1/2 in ACME intake fittings, so you can connect common automotive A/C service hoses without adapters in most cases.
Q: How deep of a vacuum can this pump achieve?
A: Listings specify an ultimate vacuum down to 50 micron, suitable for evacuating moisture and noncondensables before charging A/C systems. Always use a micron gauge to verify actual system vacuum.
