CTA Tools 8050K 3-Jaw Gear Puller - 10" Capacity - Replaces 8050B
Brand: CTA Tools
Part Number: 8050K
- The CTA Tools 8050K 3-Jaw Gear Puller is a heavy-duty pulling tool designed for removing gears, pulleys, bearings, and other press-fit components from shafts and assemblies. With a 10-inch spread and 7-ton capacity, this professional-grade puller provides strong, controlled pulling force for automotive, mechanical, and industrial service work.
- The reversible jaw design allows technicians to grip components from either the inside or outside edges, making it suitable for a wide variety of removal tasks. A precision-machined center screw ensures smooth operation while applying consistent pulling pressure.
- This updated model replaces the CTA Tools 8050B and offers the same dependable performance for demanding repair applications.
- Features:
- 3-jaw gear puller designed for removing gears, pulleys, bearings, and similar components
- 10" spread capacity for larger assemblies
- 7-ton pulling capacity for heavy-duty service
- Reversible jaws allow internal or external gripping
- Precision center thrust screw for controlled pulling force
- Suitable for automotive, mechanical, and industrial maintenance
- Replacement model for CTA Tools 8050B
- Specifications:
- Manufacturer: CTA Tools
- Part Number: 8050K
- Product Type: 3-Jaw Gear Puller
- Spread: 10" (254 mm)
- Reach: 5-1/2" (140 mm)
- Screw Length: 9" (229 mm)
- Pulling Capacity: 7 Tons (6.4 MT)
- Thread Size: 9/16" (14 mm)
- Threads Per Inch: 20 TPI
- Replaces: CTA Tools 8050B
- Interchange: 1037, 35146
Instructions:
- Hook the puller jaws onto the gear, pulley, or component being removed.
- The jaws may be reversed to grip either the inside or outside edge of the component.
- Turn the thrust screw until it contacts the center shaft and apply pressure until the jaws are secure.
- Continue slowly turning the center screw until the component is removed.
Common Names: 3-jaw gear puller, pulley puller tool, bearing puller, automotive gear removal tool, heavy-duty puller.
