Ingersoll Rand 244A-2 Air Impact Wrench, 1/2" Drive, 2" Extended Anvil, 500 ft lb Max Torque

Ingersoll Rand 244A-2 Air Impact Wrench, 1/2" Drive, 2" Extended Anvil, 500 ft lb Max Torque

• Ingersoll Rand 244A-2 air impact wrench is a 1/2 inch drive, maintenance duty model with a 2 inch extended anvil for reaching recessed fasteners. It delivers up to 500 ft lb max reverse torque at 7000 rpm with about 1300 impacts per minute; this is a standalone fastening tool, not a replacement part.
• Features:
  • 500 ft lb max reverse torque with smooth, balanced blows for stubborn fasteners in service work
  • 2 inch extended anvil improves access to deep wheel wells and recessed hardware without extra extensions
  • Steel hammer case and metal housing for durability; pressure fed lubrication to the impact mechanism
  • Power regulator and one hand forward or reverse selector for quick, controlled adjustments on the job
  • General application note: uses 1/2 inch drive impact sockets; this listing is not a model specific replacement part
• Specifications:
  • Manufacturer: Ingersoll Rand
  • Part Number: 244A-2
  • Drive Size: 1/2 inch square
  • Anvil: 2 inch extended, hog ring retainer
  • Max Reverse Torque: 500 ft lb
  • Free Speed: 7000 rpm
  • Impacts Per Minute: approximately 1300
  • Air Inlet: 1/4 inch NPT; Minimum Hose Size: 3/8 inch
  • Average Air Consumption: about 5.4 cfm; at load approximately 21 to 22 cfm
  • Overall Length: about 9.5 inch; Weight: about 6.3 lb
  • System Compatibility or Application: for use with 1/2 inch drive impact sockets on regulated 90 psi shop air; standalone fastening tool
  • Quantity: 1 tool
• The Air Impact Wrench can also be referred to as 1/2 inch air impact wrench, extended anvil impact wrench, 500 ft lb air impact, pistol grip pneumatic impact, and Ingersoll Rand 244A-2.

Ingersoll Rand designs and manufactures industrial pneumatic and cordless tools, material handling equipment, and compressed air systems for professional automotive, fleet, and manufacturing applications worldwide.

Q: What is the anvil length on the 244A-2?
A: The 244A-2 is the 2 inch extended anvil version of the 244A series, designed for better reach on recessed fasteners.

Q: What air supply should I plan for?
A: Use a regulated 90 psi system with a 3/8 inch hose to a 1/4 inch NPT inlet. Plan for about 5.4 cfm average and roughly 21 to 22 cfm at load.

Q: Is this a replacement part or a complete tool?
A: This is a complete air impact wrench. It is not a replacement part for another SKU.
